Brand new Daikin compressor JT160BATYE5 air conditioning compressor

price:USD$1880.00
discount 70% in 2018-10-15 to 2018-10-17
price: USD$ 1316.00
freight :USD$18.00,(Express)
freight :USD$7.00,(Postal parcel)
views:0
Search Similar or mail to saler or send message to saler

Pay with PayPal, PayPal Credit or any major credit card



·D series high efficiency scroll compressor
Three elements of high efficiency
The best air distribution structure is adopted
Asymmetric scroll plates are used
Fixed scroll disk with low deformation
Three elements of high reliability
The best cooling structure of motor is adopted
Adopting rolling bearing
Dry bearing
application
D type compressor used in the box body of water chiller. It is used in combination with fan coil unit system or air handling equipment. Air conditioners for offices, hotels, restaurants, hospitals, and devices for supplying industrial cooling water.



Brand new Daikin compressor JT160BATYE5 air conditioning compressor

Brand new Daikin compressor JT160BATYE5 air conditioning compressor

Brand new Daikin compressor JT160BATYE5 air conditioning compressor



Brand new Daikin compressor JT160BATYE5 air conditioning compressor



 ·Standard refrigerant R22/R407C for type D compressor

Model MODEL
A
B
C
D
E
F
G
JT212(236)D-YE(Y1L)
JT212(236)DA-Y1
450
277
228
20
275
512
171.5
JT212(236)D-P1YE
450
277
228
20
275
554.2
171.5
JT265-335D-YE(Y1L)
JT265-335DA-Y1L(Y1)
462
277
228
20
275
524
182.5
JT265-335D-P1YL
462
277
228
20
275
566.2
182.5
 ·D type refrigerant R22 for compressor type
Nominal HP
Power Supply
Model
performance
displacement
cm3/r

Measuring power supply
Refrigerating capacity
input
Power KW
Electric current
A
COP
W/W
Suction tube mm
Exhaust pipe mm
KW
BTU/H
7
380V/50Hz
Three-phase
JT212D-Y1L 380V/50Hz 21.3 73400 6.56 11.3 3.25 117.3 Φ25.4 Φ19.1
7.5 JT236D-Y1L 380V/50Hz 23.8 81900 7.27 12.4 3.27 131 Φ25.4 Φ19.1
8.5 JT265D-Y1L 380V/50Hz 26.5 91100 8.03 13.7 3.3 144.7 Φ31.8 Φ19.1
10 JT300D-Y1L 380V/50Hz 29.6 102000 8.94 15.2 3.31 163 Φ31.8 Φ19.1
11 JT315D-Y1L 380V/50Hz 30.8 106200 9.24 15.7 3.33 169.5 Φ31.8 Φ19.1
12 JT335D-Y1L 380V/50Hz 33.7 116000 10.08 17.2 3.34 184.2 Φ31.8 Φ19.1
7
380-415V/
400-440V
Three phase 50/60Hz
JT212D-YE 380V/50Hz 21.3 73400 6.56 11.3 3.25 117.3 Φ25.4 Φ19.1
400V/60Hz 24.9 85700 7.74 11.9 3.22
7.5 JT236D-YE 380V/50Hz 23.8 81900 7.27 12.4 3.27 131 Φ25.4 Φ19.1
400V/60Hz 28.1 96600 8.62 13.2 3.26
8.5 JT265D-YE 380V/50Hz 26.5 91100 8.03 13.7 3.3 144.7 Φ31.8 Φ19.1
400V/60Hz 31.5 108500 9.55 14.6 3.3
10 JT300D-YE 380V/50Hz 29.6 102000 8.94 15.2 3.31 163 Φ31.8 Φ19.1
400V/60Hz 34.9 120200 10.51 16.2 3.32
12 JT335D-YE 380V/50Hz 33.7 116000 10.08 17.2 3.34 184.2 Φ31.8 Φ19.1
400V/60Hz 39.4 136900 11.92 18.4 3.34
7 JT212D-P1YE 380V/50Hz 21.3 73400 6.56 11.3 3.25 117.3 Φ25.4 Φ19.1
400V/60Hz 24.9 85700 7.74 11.9 3.22
7.5 JT236D-P1YE 380V/50Hz 23.8 81900 7.27 12.4 3.27 131 Φ25.4 Φ19.1
400V/60Hz 28.1 96600 8.62 13.2 3.26
8.5 JT265D-P1YE 380V/50Hz 26.5 91100 8.03 13.7 3.3 144.7 Φ31.8 Φ19.1
400V/60Hz 31.5 108500 9.55 14.6 3.3
10 JT300D-P1YE 380V/50Hz 29.6 102000 8.94 15.2 3.31 163 Φ31.8 Φ19.1
400V/60Hz 34.9 120200 10.51 16.2 3.32
12 JT335D-P1YE 380V/50Hz 33.7 116000 10.08 17.2 3.34 184.2 Φ31.8 Φ19.1
400V/60Hz 39.4 136900 11.92 18.4 3.34
3/

Compressor test condition

Evaporation temperature
Condensing temperature
Supercooling degree
Superheat
ambient temperature
Compressor
7.2℃
54.4℃
8.3℃
11.1℃
35℃
 ·D type refrigerant R407C for compressor type
Nominal HP
Power Supply
Model
performance
displacement
cm3/r

Measuring power supply
Refrigerating capacity
input
Power KW
Electric current
A
COP
W/W
Suction tube mm
Exhaust pipe mm
KW
BTU/H
7
380-415V
Three phase 50Hz
JT212DA-Y1 380V/50Hz 18.9 64500 6.87 11.7 2.75 117.3 Φ25.4 Φ19.1
8.5
380-415V
Three phase 50Hz
JT265DA-Y1 400V/50Hz 23.4 79800 8.36 14.1 2.8 144.7 Φ31.8 Φ19.1
10
380-415V
Three phase 50Hz
JT300DA-Y1 400V/50Hz 26.5 90400 9.44 16 2.81 163 Φ31.8 Φ19.1
12
380-415V
Three phase 50Hz
JT335DA-Y1 400V/50Hz 29.9 102000 10.7 17.9 2.79 184.2 Φ31.8 Φ19.1
10
380V
Three phase 50Hz
JT300DA-Y1L 380V/50Hz 29.6 101000 9.55 16.4 3.1 163 Φ31.8 Φ19.1
12
380V
Three phase 50Hz
JT335DA-Y1L 380V/50Hz 33.7 115000 10.81 18.3 3.12 184.2 Φ31.8 Φ19.1

Compressor test condition

Evaporation temperature
Condensing temperature
Supercooling degree
Superheat
ambient temperature
Compressor
7.2℃
54.4℃
8.3℃
11.1℃
35℃
5℃
55℃
8℃
5℃
35℃


Model MODEL
A
B
C
D
E
JT212(236)D-TY1L(YE)
512
328
275
450
171.5
JT265(300,335)-TY1L(YE)
524
340
287
462
182.5

   ·D refrigerant R22 for parallel compressor type
Nominal HP
Power Supply
Model
performance
displacement
cm3/r

Measuring power supply
Refrigerating capacity
input
Power KW
Electric current
A
COP
W/W
Suction tube mm
Exhaust pipe mm
KW
BTU/H
7
380V/50Hz
Three-phase
JT212D-TY1L 380V/50Hz 21.3 73400 6.56 11.3 3.25 117.3 Φ25.4 Φ19.1
7.5 JT236D-TY1L 380V/50Hz 23.8 81900 7.27 12.4 3.27 131 Φ25.4 Φ19.1
8.5 JT265D-TY1L 380V/50Hz 26.5 91100 8.03 13.7 3.3 144.7 Φ31.8 Φ19.1
10 JT300D-TY1L 380V/50Hz 29.6 102000 8.94 15.2 3.31 163 Φ31.8 Φ19.1
11 JT315D-TY1L 380V/50Hz 30.8 106200 9.24 15.7 3.33 169.5 Φ31.8 Φ19.1
12 JT335D-TY1L 380V/50Hz 33.7 116000 10.08 17.2 3.34 184.2 Φ31.8 Φ19.1
7
380-415V/
400-440V
Three phase 50/60Hz
JT212D-TYE 380V/50Hz 21.3 73400 6.56 11.3 3.25 117.3 Φ25.4 Φ19.1
400V/60Hz 24.9 85700 7.74 11.9 3.22
7.5 JT236D-TYE 380V/50Hz 23.8 81900 7.27 12.4 3.27 131 Φ25.4 Φ19.1
400V/60Hz 28.1 96600 8.62 13.2 3.26
8.5 JT265D-TYE 380V/50Hz 26.5 91100 8.03 13.7 3.3 144.7 Φ31.8 Φ19.1
400V/60Hz 31.5 108500 9.55 14.6 3.3
10 JT300D-TYE 380V/50Hz 29.6 102000 8.94 15.2 3.31 163 Φ31.8 Φ19.1
400V/60Hz 34.9 120200 10.51 16.2 3.32
12 JT335D-TYE 380V/50Hz 33.7 116000 10.08 17.2 3.34 184.2 Φ31.8 Φ19.1
400V/60Hz 39.4 136900 11.92 18.4 3.34

Compressor test condition

Evaporation temperature
Condensing temperature
Supercooling degree
Superheat
ambient temperature
Compressor

7.2℃
54.4℃
8.3℃
27.8℃
35℃
